Test1_fifo1.bit Bitfile to test a BRAM based FIFO buffer at the BASYS kit Clk = 50 MHz Reset = Btn3 WRb = Btn1 RDb = Btn0 Tom = Ledx Fuld = Ledy Display ( )( )( )( )
Test1_fifo1.bit Bitfile to test a BRAM based FIFO buffer at the BASYS kit
Clk = 50 MHz
Reset = Btn3
WRb = Btn1
RDb = Btn0
Tom = Ledx
Fuld = Ledy
Display ( )( )( )( )
