Sinusgenerator version 1
Up ]

  •  Sinusgenerator.bit - Use <Sw0> to select the frequency of the output seen at <Ld0> (what do you expect to see?)

    Remember that its possible to select the system frequency: 25, 50 or 100 MHz

  •   SinusGen1.zip - Zippet project (ISE 9.2i) of the SinusGen1
